ZWO ASI678MM USB3.0 Monochrome Astronomy Camera

 ZWO ASI678MM Monochrome Astronomy Camera

Unlock the full potential of planetary and deep-sky astrophotography with the ZWO ASI678MM, powered by the advanced Sony STARVIS 2 IMX678 CMOS sensor. This professional-grade monochrome camera is designed to capture the universe in stunning detail, making it the perfect upgrade for both amateur astronomers and seasoned astrophotographers.

Key Features:

High-Performance Sensor: At the heart of the ASI678MM lies the Sony IMX678 monochrome sensor, featuring a 1/1.8" diagonal and an ultra-high resolution of 8.29 megapixels. The 2.0µm pixel size expertly balances sensitivity and detail, capturing celestial objects with precision.

Exceptional Low-Light Capabilities: With a quantum efficiency (QE) of up to 83%, this camera excels in low-light environments, ensuring vibrant images across the visible to near-infrared spectrum. Perfect for those seeking to delve into high-resolution planetary, lunar, and solar imaging.

Advanced Noise Reduction: Experience imaging like never before with zero amplifier glow and minimal dark current noise, thanks to the built-in anti-amp glow circuitry and innovative cooling technologies.

Dynamic Range and Speed: Achieve sharp, dynamic images with a full well capacity of 11,270 electrons and rapid capture speeds of up to 47.5 frames per second at full resolution. The High Conversion Gain (HCG) mode further reduces read noise at high gain settings, preserving the dynamic range.

Optimized for Modern Astrophotography

USB 3.0 Connectivity: Equipped with a high-speed USB 3.0 port, the ASI678MM facilitates seamless data transfer, allowing you to capture and process images swiftly. Achieve optimal performance with solid-state drives (SSDs) for an unmatched astrophotography experience.

Versatile Compatibility: Compatible with Mac, Windows, and Linux systems, this camera integrates effortlessly into any setup. It also supports various mount types, including 2-inch, 1.25-inch, and M42, offering flexibility for different imaging configurations.

Technical Specifications:

Sensor: Sony IMX678AAQR1-M, Monochrome

Resolution: 3840 x 2160 (8.29 Megapixels)

Pixel Size: 2.0 µm

Sensor Size: 7.68 x 4.32 mm (8.86 mm diagonal)

Quantum Efficiency: 83%

Exposure Range: 32 µs to 2000 s

Read Noise: 0.6 e- to 3.5 e-

Frame Rate: Up to 47.5 fps at full resolution

Ports: USB 3.0 Type-B, ST4 Autoguider Port

Elevate your astrophotography journey with the ZWO ASI678MM USB3.0 Monochrome Astronomy Camera—where technology meets the cosmos.
